Components coated in Titanium Nitride, which is the staple of Physical Vapor Deposition (PVD) hard coatings, solves “tribological” problems with machine components that can be coated at temperatures of 800-850° Fahrenheit.
“Tribology” is the science and engineering of interacting surfaces in relative motion. It includes the study and application of the principles of friction, lubrication, and wear.
This Nanocrystalline technology is accomplished by embedding Nanocrystalline (AICrN) grains into an amorphous matrix. Advancements allow for the formation of higher nanohardness coating with greater thermal stability than conventional coatings.
Applied using a lateral rotating cathode technology in a PVD process, materials are vaporized from a solid source in the form of atoms/molecules and then transported in the form of vapor through a vacuum, low pressure gas/plasma to the substrate where it condenses. Following the coating process the components are Micro-Polished to achieve an amazing luster that performs under conditions of high load with higher reliability over other conventional coatings.
Advantages of this coating include abrasion resistance, chemical resistance, corrosion protection, extreme temperature resistance, high wear resistance, extreme hardness, oil/fuel resistance, increased lubricity, low coefficient of friction, oxidation resistance, and low thermal conductivity.
HP proof testing, 100% using a high pressure M197 or SAAMI commercial equivalent, without evidence of failure
MPI testing after above, 100% inspection per ASTM E1444 using a standard 5 turn magnetizing coil with a current of 200 to 300 amperes. Circular and longitudinal continuous magnetization and a wet fluorescent solution shall be used. Conformance to MIL-STD-410 is required within ASTM E1444
All material, components and packaging made in the USA
Export Notice :
This product and/or its components is subject to the International Traffic in Arms Regulations (ITAR, 22 CFR Parts 120-130) and export is strictly prohibited without authorization or a license issued by the U.S. Department of State's Directorate of Defense Trade Controls. Additionally, any documents or engineering drawings, prints, etc. that can be viewed, downloaded, or printed from our Web site may contain technical data which may not be Exported outside of the United States, or released or disclosed to non-US persons (i.e. persons who are not US citizens or lawful permanent residents) inside of the United States, without prior written authorization by the relevant US Government agency. Violations of these export laws are subject to severe civil, criminal and administrative penalties.
